Spotting Scopes
9-27x56
- Model:BSH648
- Magnification: 9x -27x
- Objective Lens: 56 mm
- Angle of View: 4.6°- 2.3°
- Product description: It's only 220mm long, the 9-27x56 Spotting Scope boasts big functionality.
Key Features:
● 45° Angled Viewing
● BAK4 Porro Prism System
● Fully Multi-Coated Optics
● 55mm Objective Lens
● 6.56ft Minimum Focus Distance
● Nitrogen Filled, Waterproof & Fogproof
● 9-27x Zoom Eyepiece
● Rubber Armoring
● 1/4"-20 Rotating Tripod Collar
Overview :
It's only 220mm long, the 9-27x56 Spotting Scope boasts big functionality.Its BAK4 Porro prism and anti-reflection fully multi-coated optics deliver bright images with accurate color representation in high contrast and with minimal distortion.The maximum 27x magnification pulls distant objects in close, while birders and butterflyers will love the 8.2' close-focus distance. The 45° eyepiece places your head in a natural, comfortable position whether you are standing, sitting, or lying prone. For optimum eyepiece positioning, the mounting collar can rotate to change the orientation of the eyepiece relative to your support system. The aluminum alloy chassis is wrapped in protective rubber armoring and is nitrogen filled and O-ring sealed for a water and fogproof performance. A retractable sunshade reduces glare to improve visibility, while a stay-on case adds another layer of protection, ensuring you're ready to move quickly and quietly without fumbling for the case.
Optical Performance:
● 9-27x optical zoom magnification for close-ups or long-range viewing
● 56mm objective lens
● BAK4 Porro prism system
● Anti-reflection fully multi-coated optics help to improve light transmission, color rendition, contrast, and overall image brightness
● 243-120ft field of view at 1000 yards
● Long 20mm eye relief
● 6.2-2.1mm exit pupil
Use and Handling :
● Eyepiece set 45° for comfortable viewing position whether sitting, standing, or lying prone
● Dual focusing knob for fine focusing
● Rotating tripod collar allows for precise eyepiece positioning for optimal viewing angle
● Twist-up rubber eyecup for use with or without eyewear
● 1/4""-20 mount to fit most photo/video/field tripods and quick-release plates
Construction Details:
● Ergonomic and compact construction
● Nitrogen filled and O-ring sealed for a water and fogproof performance
● Rubberized covering provides for a sure grip
● Waterproof
● Weight: 560g
Performance :
● 45° Angled Viewing
● BAK4 Porro Prism System
● Fully Multi-Coated Optics
● 55mm Objective Lens
● 6.56ft Minimum Focus Distance
● Nitrogen Filled, Waterproof & Fogproof
● 9-27x Zoom Eyepiece
● Rubber Armoring
● 1/4"-20 Rotating Tripod Collar
Overview :
It's only 220mm long, the 9-27x56 Spotting Scope boasts big functionality.Its BAK4 Porro prism and anti-reflection fully multi-coated optics deliver bright images with accurate color representation in high contrast and with minimal distortion.The maximum 27x magnification pulls distant objects in close, while birders and butterflyers will love the 8.2' close-focus distance. The 45° eyepiece places your head in a natural, comfortable position whether you are standing, sitting, or lying prone. For optimum eyepiece positioning, the mounting collar can rotate to change the orientation of the eyepiece relative to your support system. The aluminum alloy chassis is wrapped in protective rubber armoring and is nitrogen filled and O-ring sealed for a water and fogproof performance. A retractable sunshade reduces glare to improve visibility, while a stay-on case adds another layer of protection, ensuring you're ready to move quickly and quietly without fumbling for the case.
Optical Performance:
● 9-27x optical zoom magnification for close-ups or long-range viewing
● 56mm objective lens
● BAK4 Porro prism system
● Anti-reflection fully multi-coated optics help to improve light transmission, color rendition, contrast, and overall image brightness
● 243-120ft field of view at 1000 yards
● Long 20mm eye relief
● 6.2-2.1mm exit pupil
Use and Handling :
● Eyepiece set 45° for comfortable viewing position whether sitting, standing, or lying prone
● Dual focusing knob for fine focusing
● Rotating tripod collar allows for precise eyepiece positioning for optimal viewing angle
● Twist-up rubber eyecup for use with or without eyewear
● 1/4""-20 mount to fit most photo/video/field tripods and quick-release plates
Construction Details:
● Ergonomic and compact construction
● Nitrogen filled and O-ring sealed for a water and fogproof performance
● Rubberized covering provides for a sure grip
● Waterproof
● Weight: 560g
Performance :
Model: | BSH648 |
Specification | 9 - 27x56mm |
Magnification | 9x - 27x |
Objective Lens Diameter | 56 mm |
Angle of View | 4.6°- 2.3° |
Field of View | 81 - 40 m @ 1000 m |
Field of View | 243 - 120 ft @1000 yds |
Minimum Focus Distance | 2 m |
Exit Pupil | 6.2 - 2.0 mm |
Eye Relief | 20 - 17 mm |
Number Of Lens | 11Pcs / 7 Groups |
Focus Type | Center |
Prism Type | Roof (BAK-4) |
Lens Coating | Fully Multi |
Eyecups | Twist-up |
Waterproof | Yes / IPX-6 |
Weight | 560 g |
Size | 220x70x135 mm |
